APC AP9614 — Dry Contact I/O Card. Manufacturer reference.
APC · Full reference: AP9614
Ask about this model
Manufacturer reference
Manufacturer details describe the cited version. Confirm the exact unit and intended system.
- Product type
- Dry Contact I/O Card
- Device format
- SmartSlot Card
- Monitoring
- External UPS environmental sensors
- Output interface
- Relay outputs
- Input interface
- Input contacts
- Front interfaces
- Universal I/O
- USB interface
- Present
- Range of Product
- Management Options and Cables
- Provided Equipment
- User Manual, USB cable
- Product or Component Type
- Dry contact
- Number of rack unit
- 0U
- Cable length
- 0.522 ft (0.159 m)
- Rated voltage
- 24 V
- Line Rated Current
- 0…200 mA
- Power supply type
- Self powered via SmartSlot
- Height
- 1.5 in (3.8 cm)
- Width
- 4.8 in (12.1 cm)
- Depth
- 5.04 in (12.8 cm)
- Net Weight
- 0.44 lb(US) (0.20 kg)
- Mounting Mode
- Not rack-mountable
- Ambient Air Temperature for Operation
- 32…104 °F (0…40 °C)
- Operating altitude
- 0...10000 ft, 0...50000 ft
- Ambient Air Temperature for Storage
- 5…149 °F (-15…65 °C)
- Storage altitude
- 0…50000 ft (0…15240 m)
Selection notes
- Specifications are from the manufacturer's official product page.
- ISD stock, price, Malaysian warranty and delivery are confirmed separately. Confirm the exact model suffix and supplied revision.
Official documents
Manufacturer source checked 2026-10-26. The supplied unit and local terms require confirmation.
