APC SURT023M — Marine UPS Filter. Manufacturer reference.
APC · Full reference: SURT023M
Ask about this model
Manufacturer reference
Manufacturer details describe the cited version. Confirm the exact unit and intended system.
- Product type
- Marine UPS Filter
- Load capacity
- 3000 VA
- Input voltages
- 208V, 220V, 230V, 240V
- Rack height
- 1U
- Main Input Voltage
- 208 V, 220 V, 230 V, 240 V
- Product or Component Type
- Filter
- Main Output Voltage
- 200 V, 208 V, 220 V, 230 V, 240 V
- Input Connection Type
- IEC 60320 C20
- Number of rack unit
- 1U
- Cable length
- 8 ft (2.4 m)
- Number of cables
- 1
- Color
- Black
- Height
- 1.7 in (44 mm)
- Width
- 17.008 in (432 mm)
- Depth
- 11.0 in (279 mm)
- Net Weight
- 11.22 lb(US) (5.09 kg)
- Mounting Location
- Front
- Mounting preference
- No preference
- Mounting Mode
- Not rack-mountable
- Input Frequency
- 47...63 Hz
- Max line current
- 16 A
- Input current limits
- 16 A
- permissible voltage
- 100…240 V
- Max current draw
- 16 A
- Ambient Air Temperature for Operation
- 32…131 °F (0…55 °C)
- Relative Humidity
- 0…95 %
- Operating altitude
- 0...10000 ft
- Ambient Air Temperature for Storage
- -13…167 °F (-25…75 °C)
- Storage Relative Humidity
- 0…95 %
- Storage altitude
- 0…50000 ft (0…15240 m)
Selection notes
- Specifications are from the manufacturer's official product page.
- ISD stock, price, Malaysian warranty and delivery are confirmed separately. Confirm the exact model suffix and supplied revision.
Official documents
Manufacturer source checked 2026-10-26. The supplied unit and local terms require confirmation.
