Hikvision DS-TMG320 — 32 Series Barrier Gates. Manufacturer reference.
Hikvision · Full reference: DS-TMG320
Ask about this model
Manufacturer reference
Manufacturer details describe the cited version. Confirm the exact unit and intended system.
- Product type
- 32 Series Barrier Gates
- Barrier Housing Material
- SGCC
- Barrier Housing Thickness
- 1.5 mm
- Barrier Housing Color
- Black background with silver pattern
- Boom Pole Installation Height
- 880 mm
- Body Indicators
- without Indicator
- Matched Boom Pole Type
- DS-TMG320-ML/DS-TMG320-MR: DS-TMG001-3D(3m octagonal), DS-TMG001-3D(4m octagonal), DS-TMG001-3D(2.6-4m), DS-TMG002-3D(1.5+1.5m), DS-TMG001-6L(3m)(1.4mm), DS-TMG002-6L(1.5+1.5m) DS-TMG320-LL/DS-TMG320-LR: DS-TMG001-3D(3.6-6m), DS-TMG002-3D(2+2m), DS-TMG002-3D(2.5+2.5m), DS-TMG001-6L(4m)(1.4mm), DS-TMG002-6L(2+2m)
- Rising Speed
- 3m: 3s, 4m: 3.5s, 2.6-4m telescopic: 4s, 1.5+1.5 m folding: 3s, 3.6-6 m telescopic: 6.5s, 2+2 m folding: 4s, 2.5+2.5 m folding: 5.5s, 3m light: 3s, 4m light: 3.5s, 1.5+1.5m light folding: 3s, 2+2m light folding: 4s
- Falling Speed
- 3m: 3s, 4m: 3.5s, 2.6-4m telescopic: 4.5s, 1.5+1.5 m folding: 4s, 3.6-6 m telescopic: 7.5s, 2+2 m folding: 6s, 2.5+2.5 m folding: 7s, 3m light: 3s, 4m light: 3.5s, 1.5+1.5m light folding: 3s, 2+2m light folding: 4.5s
- Boom Pole Direction
- DS-TMG320-ML/DS-TMG320-LL: left DS-TMG320-MR/DS-TMG320-LR: right
- Boom Pole Falling Delay
- 10 ~ 600 s(30s by default)
- Motor Type
- DC Brushless Motor
- Number of Cycles
- 2500000
- Working Voltage
- 24VDC
- Remote Controller Frequency
- 433.5 MHz
- Max. Number of Remote Controller Binding
- 64
- Consumption
- 100W
- Temperature and Humidity
- Temperature: -30 °C to 70 °C (-22 °F to 158 °F)
- Rising Boom Pole for Poweroff
- Optional, order emergency barrier-lifting module independently
- Duty Cycle
- 100%
- Rising to Limit
- 1 group
- Falling to Limit
- 1 group
- Open
- 1 group
- Close
- 1 group
- RS-485
- 1 group
- Stop
- 1 group
- IR/Vehicle Detector/Radar
- 1 group
- LED Indicators
- 1 group
- RF
- CE-RED EN 61000-3-3: 2013+ A1:2019+A2:2021 EN IEC 61000-3-2: 2019+A1:2021+A2:2024 EN 301 489-1 V2.2.3 EN 301 489-3 V2.3.2 EN 301 489-17 V3.3.1 EN 300 328 V2.2.2 EN 300 220-1 V3.1.1 EN 300 220-2 V3.1.1 EN IEC 62311:2020
- EMC
- CE-EMC EN 50130-4: 2011+A1:2014 EN 55032: 2015+A11:2020+A1:2020 EN 55035: 2017+A11:2020 EN 61000-3-3: 2013+ A1:2019+A2:2021 EN IEC 61000-3-2: 2019+A1:2021+A2:2024
- Security
- CE-LVD EN 62368-1: 2014 + A11: 2017 EN IEC 62368-1:2020+A11:2020
- Environment
- ROHS
- Protection
- IP54
- Power Supply
- 110/220 VAC(switchable)
- Bluetooth
- supported
- Remote Control Distance
- 20m
- Dimensions
- 1040 × 340 × 298.3 mm (40.94 × 13.39 × 11.74 inch)
- Dimensions (with Package)
- 1143 × 436 × 403mm(45 × 17.17 × 15.87inch)
- Weight (with Package)
- 40.9 kg (90.17 lb.)
Selection notes
- Specifications are from the manufacturer's official product page.
- Enquiry reference DS-TMG320-ML. The manufacturer's product page is titled DS-TMG320; confirm the exact suffix, lens or option required.
- ISD stock, price, Malaysian warranty and delivery are confirmed separately. Confirm the exact model suffix and supplied revision.
