IS DistributionsEnquireDS-2CE56D0T-IRPF
Hikvision DS-2CE56D0T-IRPF is a 2 MP fixed-lens indoor turret camera with 1920 × 1080 resolution. Smart IR illumination reaches up to 20 m.
Hikvision · Full reference: DS-2CE56D0T-IRPF
Choose quantityManufacturer reference
Manufacturer details describe the cited version. Confirm the exact unit and intended system.
Camera
- Image Sensor
- 2MP CMOS image sensor
- Signal System
- PAL/NTSC
- Frame Rate
- PAL: 1080p@25fps NTSC: 1080p@30fps
- Resolution
- 1920 (H) × 1080 (V)
- Min. illumination
- 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
- Shutter Time
- 1/25 (1/30) s to 1/50,000 s
- Lens
- 3.6 mm, 2.8 mm, 6 mm fixed lens
- Horizontal Field of View
- 103° (2.8 mm), 82.2° (3.6 mm), 54° (6 mm)
- Lens Mount
- M12
- Day & Night
- IR cut filter
- Angle Adjustment
- Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- Synchronization
- Internal synchronization
Menu
- AGC
- Low/middle/high
- Day/Night Mode
- Smart/color/BW(Black and White)
- Backlight Compensation
- Yes
- DWDR
- Yes
- Language
- English, Chinese
- Functions
- Brightness, Sharpness, DNR, Mirror
Interface
- Video Output
- 1 HD analog output
- Switch Button
- TVI/AHD/CVI/CVBS
General
- Operating Conditions
- -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
- Power Supply
- 12 VDC±15%
- Power Consumption
- Max. 4 W
- Material
- Plastic
- IR Range
- Up to 20 m
- Dimension
- Φ 89.9 mm × 70.1 mm (3.54" × 2.76")
- Weight
- Approx. 250 g (0.55 lb.)
- Intended Installation
- Indoor
Accessories
- Listed Accessories
- DS-1272ZJ-110-TRS; DS-1275ZJ-SUS; DS-1276ZJ-SUS; DS-1H18; DS-1280ZJ-X
Selection notes
- The documented specifications apply to the cited manufacturer version. Confirm the supplied hardware, firmware and accessory configuration.
- Fixed lens options and their individual fields of view are preserved. Select the lens when ordering. Accessory listings do not establish package contents. Only this exact model and cited PDF edition are used; resolution/frame-rate, illumination and audio features are not inherited from neighbouring suffixes.
- Readers, locks, power supplies, batteries, licences and other accessories are not assumed to be included. ISD confirms specification, compatibility, supply, price, lead time and local warranty separately.
Official documents
Manufacturer source checked 2026-09-10. The supplied unit and local terms require confirmation.
