DS-3E0105P-E

Hikvision DS-3E0105P-E — 4 Port Fast Ethernet Unmanaged POE Switch. Manufacturer reference.

Hikvision · Full reference: DS-3E0105P-E

Choose quantity
Hikvision DS-3E0105P-E 4 Port Fast Ethernet Unmanaged POE Switch
Image: Hikvision official product image

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

Product type
4 Port Fast Ethernet Unmanaged POE Switch
Storage Temperature
Temperature: -40℃-70℃
Power Supply
51V DC, 1.25A
Weight
0.299kg
Storage Humidity
Humidity: 5%-90% , non-condensing
Surge Protection
4KV
Power Consumption
≤63W
Switching Capacity
1Gbps
Store-and-forward
Store-and-forward
Max. Forwarding Rate
0.74Mpps
Working Mode
Extend On:250m,10M,CAT 5e, Extend Off:100m
PoE Standard
IEEE802.3af, IEEE802.3at
PoE Power Budget
58W
PoE Port
4, 10/100Mbps RJ45 ports
Uplink Port
1, 100M Ethernet Port
Network Ports
5
High-priority Port
Port 1
Network Protocol
IEEE802.3,802.3u,802.3x, 802.3af, 802.3at

Selection notes

  • Specifications are from the manufacturer's official product page.
  • ISD stock, price, Malaysian warranty and delivery are confirmed separately. Confirm the exact model suffix and supplied revision.

Official documents

Manufacturer source checked 2026-10-30. The supplied unit and local terms require confirmation.
