DS-3E2528P

Hikvision DS-3E2528P Network Switch manufacturer reference

Hikvision · Full reference: DS-3E2528P

Choose quantity
Hikvision DS-3E2528P Network Switch
Image: Hikvision official product image

Manufacturer reference

Manufacturer details describe the cited version. Confirm the exact unit and intended system.

Product type
Network Switch
Ports
24 × 1 Gigabit PoE port,4 × 1 Gigabit combo
PoE Standard
IEEE 802.3af,IEEE 802.3at
Switching Capacity
Whole-Device Performance: 336 Gbps
Packet Forwarding Rate
Whole-Device Performance: 51 Mpps
PoE Power Budget
370 W
Dimensions (W × H × D)
440.00 mm × 44.00 mm × 210.00 mm
Net Weight
3.1 kg (6.83 lb)
Operating Temperature
-10 °C to 50 °C (14 °F to 122 °F)
Operating Humidity
10% to 90% (no condensation)
Power Supply
100-240 VAC, 50/60 Hz
Power Consumption
17 W
MAC Address Table
8 K
PoE Power Pin
1/2 (+), 3/6 (-)
VLAN
Support IEEE 802.1Q (VLAN), 4096 VLAN IDs Support GVRP Support QinQ Support VLAN based on MAC/protocol/IP subnet/policy/port Support Private VLAN Support 1:1 and N:1 VLAN mapping functions
Management Method
Support Console, Telnet, SSH Support web, http, https Support FTP, TFTP, Xmodem, SFTP Support SNMP V1/V2c/V3 Support RMON Support NTP
Multicast
Support IGMP v1/v2/v3 Snooping Support IGMP V1/V2/V3 Support MLD Snooping v1/v2 Support MLD v1/v2
HK-SFP-1.25G-1310
HK-SFP-1.25G-20-1
-DF-MM
550

Selection notes

  • ISD stock, price, Malaysian warranty and delivery are unverified. Confirm the exact model suffix and supplied revision.

Official documents

Manufacturer source checked 2026-10-25. The supplied unit and local terms require confirmation.
